| Model | GTWY601 | GTWY801 | GTWY1001 | GTWY802 | GTWY1002 | GTWY1202 |
| Capacity(kg) | 150 | 125 | 125 | 300 | 250 | 200 |
| Max. Platform Height (m)H1 | 6 | 8 | 10 | 8 | 10 | 12 |
| Max. Working Height (m)H2 | 8 | 10 | 12 | 10 | 12 | 14 |
| Platform Size (m) | 0.63×0.64 | 0.63×0.64 | 0.63×0.64 | 1.28×0.66 | 1.54×0.66 | 1.54×0.66 |
| Overall Length (m)A | 1.42 | 1.42 | 1.42 | 1.53 | 1.79 | 1.79 |
| Overall Width (m) B | 0.82 | 0.82 | 0.82 | 0.82 | 0.82 | 0.87 |
| Overall Height (m) H3 | 1.92 | 2.00 | 1.90 | 1.81 | 1.86 | 2.03 |
| Outrigger Footprint(L/W) | 1.90×1.75 | 1.90×1.75 | 1.90×1.75 | 1.65×1.66 | 2.13×1.89 | 2.13×1.94 |
| Ground Clearance (m) | 0.06 | 0.06 | 0.06 | 0.08 | 0.08 | 0.08 |
| Wheelbase (m) | 1.11 | 1.11 | 1.11 | 1.18 | 1.44 | 1.44 |
| Front wheels size (inch) | 5 | 5 | 5 | 8 | 8 | 8 |
| Real wheel (inch) | 8 | 8 | 8 | 8 | 8 | 8 |
| Battery | 2-12V/65Ah | |||||
| Integrated charger | 12V/15A | |||||
| Lifting Motor (AC) | 110-230V/0.75KW | 110-230V/1.5KW | ||||
| Lifting Motor (DC) | 12V/0.75KW | 12V/1.5KW | ||||
| Lifting time (S) | 38 | 44 | 46 | 62 | 70 | 75 |
| Lowering time (S) | 35 | 38 | 40 | 43 | 46 | 54 |
| Self weight (kg) | 415(AC)
450(DC) |
450(AC)
485(DC) |
490(AC)
525(DC) |
630(AC)
670(DC) |
730(AC)
770(DC) |
825(AC)
865(DC) |
